Specifications
Engine
| Engine type: |
four-stroke SOHC single cylinder, 4 valves, EFI |
| Displacement: |
781 ccm |
| Max. horsepower: |
43 kW |
| Ignition: |
CDI |
| Cooling system: |
liquid cooling + electric fan |
Drive system
| Driveline: |
2x4 / 4x4 electrically selectable |
| Transmission: |
automatic CVT clutch with reverse (L / H / N / R) + engine brake |
| Front differential lock: |
electric |
CHASSIS
| Power steering: |
EPS electric power steering |
| Front suspension: |
independent, double A-arms |
| Rear suspension: |
independent, double A-arms |
| Front suspension: |
hydraulic shock absorbers, adjustable spring preload |
| Rear suspension: |
hydraulic shock absorbers, adjustable spring preload |
| Brake system: |
hydraulic discs |
| Front tires: |
25 x 8 - 12 |
| Rear tires: |
25 x 10 - 12 |
Dimensions and weights
| Overall length: |
2 390 mm |
| Overall width: |
1 200 mm |
| Overall height: |
1 495 mm |
| Ground clearance: |
310 mm |
| Wheelbase: |
1 440 mm |
| Dry weight: |
362 kg |
| Fuel tank capacity: |
21 liters |
| Front rack: |
34 kg, composite, non-slip surface |
| Rear rack: |
68 kg, composite, non-slip surface |
| Hitch Towing Rating: |
226 kg (road) |
Standard features
|
Electric power steering EPS, 2500 lbs electric winch, homologated trailer hitch, composite racks front and rear, digital multifunction display, 12" alloy wheels, front bumper, handguards
|
HOMOLOGATION
| Homologated in category: |
T3b |
Images and illustrations are only for information purposes and may vary depending on your market. Some vehicles may be shown with optional equipment.
Distributor reserves the right to make changes at any time, without prior notice or obligation, to specifications, equipment, accessories, colors and other product features.
