TGB BLADE 600 LTX 4x4

BLADE 600 LTX 4x4

  • Long 2-Up wheelbase
  • LED Matrix headlights
  • 2x4 / 4x4 drive with differential lock
  • 3000lbs Electric Winch
  • Composite racks front and rear
  • Trailer hitch
  • Front bumper
  • Alloy wheels

Specifications

Engine

Type: four-stroke single cylinder, SOHC, EFI
Displacement: 561 cc
Bore x stroke: Ø 95 x 79,2 mm
Compression ratio: 10,2 : 1
Max. horsepower: 38,5 k (28,3 kW) / 6500
Max. torque: 53,6 Nm / 5500
Cooling system: liquid + oil cooled, electric fan

Drive system

Driveline: 2x4 / 4x4, electrically selectable
Transmission: automatic, CVT clutch with reverse, L / H / N / R / P, engine braking
Front differential lock: electric
Rear differential lock: electric (L7e)

CHASSIS

Front suspension: independent, double A-arms
Rear suspension: independent, double A-arms
Front suspension: hydraulic shock absorbers + 5-position adjustable spring preload
Rear suspension: hydraulic shock absorbers + 5-position adjustable spring preload
Brake system: hydraulic discs
Front tires: AT25 x 8 - 12
Rear tires: AT25 x 10 - 12

Dimensions and weights

Overall length: 2280 mm
Overall width: 1250 mm
Overall height: 1420 mm
Ground clearance: 320 mm
Seat height: 940 mm
Wheelbase: 1450 mm
Curb weight: 444 kg
Fuel tank capacity: 18 L

INSTRUMENTS

Digital multifunction display: tachometer, speedometer, odometer, trip, and hour meters, fuel gauge, temperature, clock
Indicators: 4x4 drive, gear engaged, engine overheating, engine oil, turn signals, lighting

Standard features

Electric selectable 2x4 / 4x4 drive, passenger seat with handles and backrest, 8-spoke alloy wheels 14", Maxxis Bighorn tires, braided brake hoses, composite front and rear racks, handguards, front bumper, 3000 lbs electric winch, homologated trailer hitch, 12V socket, Full LED matrix headlights, LED daytime running lights, LED turn signals, LED tail lights

HOMOLOGATION

Road legal: ✔


Images and illustrations are only for information purposes and may vary depending on your market. Some vehicles may be shown with optional equipment.
Distributor reserves the right to make changes at any time, without prior notice or obligation, to specifications, equipment, accessories, colors and other product features.
